Proving Unit for HV Non-Contact Detectors

This Proving Unit for HV Non-Contact Detectors is designed to be used in conjunction with High Voltage non-contact voltage detectors such as the HP300. The Unit produces an EMF (Electro-magnetic field) which can be detected to prove the detector it is working correctly. They produce enough EMF to allow HV Non-Contact detectors to be tested at up to 500,000 volt at a distance of 50 mm.

Features

Suitable of testing HV Non-Contact Detectors up to 500,000 Volts.
Always test your equipment so you don’t get caught out by a faulty Tester.
Sensor plate within the unit allows for directional checks.

Specifications

Battery2x PP3 9 Volt
Battery Life: 2 hours continuous
Battery Life: ON (no alarm) 140+ Hours ON (self test) 90+ Hours ON (alarm on) 60+ Hours
Diameter: 51.5 mm
Dimensions: L= 230mm W= 65.85mm Cap diameter 90mm
Frequency: 300Hz
Internal Voltage: 1000 Vrms
IP rating: IP 63
Length: 185 mm
Light source: 3*High intensity LED
Max Testing Voltage: 500,000 Volts
Operating temperature: -10 to 65°C (14 to 149°F)
Sound Source: Electromagnetic piezo 85 dB @ 5cm
Voltage sensing range: 50V AC to 750KV AC
Weight: 425 grams
Weight: (no Batteries)300g
